SPECIFICATION
Dimension
Width x Length x Height: | 747×2,020×1,145 mm. |
Wheelbase: | 1,350 mm. |
Height from floor to seat: | 815 mm |
Height from floor to machine: | 150 mm. |
The narrowest turning circle: | 35 degrees |
Net weight: | 155 kg |
Engine
Engine model: | 1 cylinder, 4 stroke, SOHC, 2 valve |
Cylinder volume: | 164.6 cc |
Top Power: | 17.8BHP@9000rpm |
Max Torque: | 16.0NM@6000RPM |
Cooling: | Liquid-cooled |
Bore x Stroke: | 65.5 x 58.8 mm. |
Ignition system: | Electronic Control – FI |
Ratio: | 11: 1 |
Gear system: | 6 speed |
Brake
Brake system: | Hydraulic Brake |
Front brake: | Disc brake / 2 pot |
Rear brake: | Disc brake / 1 pot |
Front disc brake site: | 276 mm |
Rear disc brake site: | 220 mm |
Tires / Wheels
Front / rear wheel: | 17 inches |
Front wheel size: | 100/80 (Tubeless) |
Rear wheel size: | 140/70 (Tubeless) |
Rubber wind: | Front 33 psi | Rear 36 psi |
Electrical
Headlight | DRL: | LED |
Tail Lights | brake lights: | LED |
Turn signal | emergency light: | LED |
Battery: | 12V 6.3Ah |
Meter: | Full LED Digital Meter |
Frame
Body structure: | Trellis frame |
Trail distance: | 138 mm |
Caster angle: | 25 degrees |
Fuel system
Fuel type: | Gasohol 91,95 |
Fuel capacity: | 11 Litres. |
Chain drive
Chain: | Regular Ring |
Front sprocket: | 16 |
Rear sprocket: | 47 |
Suspension
Front shock absorber: | Upside down |
Rear shock absorber: | YSS 7 levels adjustable
Mono Shock with Multi Link |
